Helios Hera 350

CNC Gear Hobbing Machine
4.2 DP
Max Pitch Rating
1,250
RPM Hob Speed
7
CNC Axes

High-speed hob head with CNC shifting:
Automatic retraction of X-axis during power failure, preventing hob damage.

‍

Direct drive torque motor for the work spindle:
Driven via FANUC® torque motor.

‍

Flexible standard dialogue program offering:
One or two gears on a single workpiece.
Radial, axial, climb, and/or conventional hobbing on single- or two-cut cycle.
Crowning (lead modification) and deburring using two equal hobs.
Automatic shifting over broken hob section.
Optional re-hobbing (skiving).

‍

CNC by FANUC® 0i-MF with 6 axes (optional 7):
Tangential position of hob head (shifting) by CNC.

‍

Quality components and construction:
Precision, repeatability, and control with linear scales on the X-axis.
Cast iron machine base for optimum stability and damping.

Bolstering your quality and productivity.
The Hera 350 vertical CNC gear hobbing machine combines advanced technology, precision components, and economic pricing to enable profitable production of high-quality spur gears, helical gears, and other hobbed profiles.

Automation options for the Helios Hera 350

Each option below can be configured for this machine to match your part, batch size, and cell layout. Our applications team will help you choose the right setup.

Ring Loader
Ring Loader
Rotary Conveyor
Rotary Conveyor
Linear Conveyor
Linear Conveyor
Industrial Robot
Industrial Robot
Cobot
Cobot
Automation cell configured for this machine

Helios Hera 350

Technical Specifications
Metric / Imperial
Max Pitch Rating
6.00 mn / 4.2 DP
Max Workpiece Diameter
350 mm / 13.78 in
Minimum Axial Position
150 mm / 5.91 in
Maximum Axial Position
470 mm / 18.50 in
Min Axial Position
150 mm / 5.91 in
Max Axial Position
470 mm / 18.50 in
Cutter Head Radial Travel
275 mm / 10.83 in
Min. Radial Position of Cutter Head
6.00 mn / 4.2 DP
Max. Radial Position of Cutter Head
310 mm / 12.20 in
Total Tailstock Travel
350 mm / 13.78 in
Min. Tailstock Position
410 mm / 16.14 in
Max. Tailstock Position
760 mm / 29.92 in
Max. Work Spindle Speed
500 rpm
Max. Spindle Speed
1,250 rpm
Max. Hob Diameter
150 mm / 5.91 in
Max. Cutter Width
200 mm / 7.87 in
Max. Cutter Shift
180 mm / 7.09 in
Width
2,920 mm / 114.96 in
Depth
2,375 mm / 93.50 in
Height
2,650 mm / 104.33 in
Weight
9,800 kg / 21,600 lb
Total Connected Load
35 kVA
Electrical Connection
220V, 3 phase, 60 Hz
